Window Interlock Roller 1747 Series
Height
2 Rollers 3 Rollers 4 Rollers A B C D
558.8mm 22" 1747-2200-N-10-2 276.9mm 10.9" 160.6mm 6.323"
660.4mm 26" 1747-2600-N-10-2 378.5mm 14.9" 262.2mm 10.323"
762.0mm 30" 1747-3000-N-10-2 480.1mm 18.9" 363.8mm 14.323"
863.6mm 34" 1747-3400-N-10-2 1747-3400-N-10-3 581.7mm 22.9" 245.1mm 9.65" 465.4mm 18.323"
965.2mm 38" 1747-3800-N-10-2 1747-3800-N-10-3 683.3mm 26.9" 295.9mm 11.65" 567.0mm 22.323"
1066.8mm 42" 1747-4200-N-10-2 1747-4200-N-10-3 784.9mm 30.9" 346.7mm 13.65" 668.6mm 26.323"
